We evaluated our alternatives and also made a decision to place in an air duct follower as well as below is just how I mounted it. www.butyltape.org After that cover the whole setting up with even more air duct insulation to maintain all air going through the air ducts and also not leaking out. If any type of air leakages out, you could have condensation outside of the follower real estate. This water could leak down and also destroy your ceiling. I make use of aluminum foil tape with a fiberglass strengthened cellular lining. I likewise utilize an aluminum foil tape for securing joints as well as joints versus wetness and also vapor on aluminum foil coat insulation.
Just what is an air duct follower. It is a follower that is put in the ductwork in your house to removal air from one component of your home to an additional. Why did we include an air duct follower inside the ductwork in our residence? It is since we have a 2nd flooring that consists of a workplace, a shower room and also just what we call the craft area. Our a/c unit device simply might not obtain adequate air to the upstairs. Throughout the summer season, it was constantly as well warm as well as throughout the cold weather it was constantly as well chilly.
After the electric job is finished, the last staying item of insulation will certainly be secured around the follower.
The following action is to reattach the supply air duct to the follower. Once more glide the Mylar lining over the beyond the follower real estate and also tape it utilizing Aluminum foil Sealer tape, mastic tape or butyl tape. All these tapes are a steel dealt with tape with a soft foam cellular lining to secure the tape to the air duct. It is truly sticky things as well as it functions wonderful! Ensure you secure whatever as you do not desire any type of air leakages.
The air duct follower itself is simply a difficult galvanized steel tube with the follower installed in it as well as 2 cords socializing with a plastic grommet. I installed a conventional steel electric box sideways of the follower real estate that will certainly permit me to attach all circuitry in a safeguarded unit. I truly despise to see cables loosened as well as simply linked with each other. Additionally, the National Electric Code needs it.
I after that reduced right into the flex air duct as well as drew the Mylar as well as fiberglass product back.
I looked for the air circulation instructions arrowhead on the side of the follower to earn certain I did not have the follower encountering the incorrect instructions. After that I put the it.
Never ever utilize the grey fabric tape as it is not ranked for this sort of use.
I reduced open the supply air duct prior to it entered into a supply circulation box. The circulation box provided our upstairs signs up. Our air duct was 12 inches, so placing a 12 inch follower was not a huge bargain.
We had air ducts that did not go anywhere and/or were not sized properly for the air circulation needed. When the brand-new a/c was placed in, that was all repaired with the exception of the air duct mosting likely to the 2nd flooring.
An atmospheric pressure button was mounted in the riser air duct to instantly transform the follower on or off when the a/c device switches on as well as off downstairs. The goal is to have totally automated activity with marginal electric use.
As a short-term step to see if every little thing functioned, I wired the follower electric motor to an expansion cable as well as connected it in. Instantly, there was trendy air in the workplace location. Within the hr, the temperature level coincided on both floorings.
The brand-new COOLING AND HEATING system we had actually set up in our house in 2015 was meant to be big sufficient to warmth and also cool down the whole residence. The issue ended up that when your house was constructed, the preliminary specialist made some obvious blunders.
Currently, to earn it irreversible, I set up a 4×4 electric box. It was geared up with an auto/manual override button and also a variable rate electric motor control.
